passive and active detectors can be connected to one loop. Combined loops applying 2- and 4- wire wiring diagrams.
low current consumption at the expense of usage of fire alarm loops with terminal capacitor, dynamic power of logical loop (discrete inputs);
outputs: "Output", "Fire";
three programmable outputs with circuit integrity control; three outputs of "open collector" type without circuit integrity control; output relay on two blocks of transfer contacts (factory default
Fault output); user-friendly controls and indications: simple menu (easy-to-use like a simple mobile phone);
digital display with large highlighted characters;
standard phone key pad;
continuous numbering (addressing) of each object (loop, output), communication blocks and interface collector;
galvanic decoupling of blocks, providing higher reliability and repairability of the panel;
possible arrangement of hierarchic group of up to 20 panels with integrated control and control in compliance with the national construction requirements DBN 2.5.56-2010;
BSKM-1 interface GSM module can be connected for communication with central monitoring stations.
Specifications
AC supply voltage: 220 (+22-33) V (50±1)
Internal power supply:12 V or 24 V;
Back-up power:
12 V sealed non-spillable lead-acid rechargeable battery (one battery for 12V panels, two batteries - for 24V panels)
Max battery capacity: 12 Ah
Max AC power 35 W
Zone voltage:
20 V to 30 V;
24 V power voltage: from 20 V to 30 V;
12 V power voltage: from 9,5 V to 15 V;
Zone current:30 mA
Total zone signaling line (wire) resistance without EOL resistor: 470 Ohm;
Leakage resistance between zone lines and between each zone line and panel's enclosure:50 kOhm;
Output commutation current of each I/O channel: 50 mA;
Output commutation current with full load control: 200 mA
Invariable panel's settings:
sound signal is restored when a new event appears;
